Drilling Equipment
EU Stage V / US EPA Tier 4 Final compliant diesel engine
TSP device (Torque/Speed Potentiometer)
Depth measurement device with on-board screen
Automatic control of the rotary motors displacement
Rotary knockback system for quick tool discharge
Main and auxilairy winch controlled descent type
Hoist limit switch on main rope
Quick-release hydraulic couplers
Swivel head on main rope
Aux rope hooking point
Heavy duty steel undercarriage
Transport security lugs on crawler units
On board lighting set
On board tool box
ROPS compliant cab with optimum visibility, adjustable ergonomic
seat, joystick controls, acoustic and optic warning
FOPS Level 1 compliant top-cab protective grid
Heat and air conditioning system
Mast verticality device with on-board screen
Digital screen for engine parameters control
Radio with MP3 player and USB plug
On-board emergency stop button
External emergency stop button for ground operator
Limit switches on the cathead, on the mast and on the kingpost
Compact Rotary Drilling Rig
Yanmar 4TNV98CT Turbo Diesel (EU Stage V / EPA Tier 4 Final)
53.7 kW / 73.0 HP
35 kNm / 25,815 ft·lbs
0-60 rpm
48 kN / 10,790 lbs
130 kN / 29,224 lbs
115 kN / 25,852 lbs
22 m / 72.0 ft
1,500 mm / 59.1 in
11,500 kg / 25,353 lbs
